Mariadb installed on a Raspberry Pi

Database FSR

Table structure for table Equipment

Column	Type	Null	Default
EquipmentCode	int(11)	No
EquipmentDesc	text	No

Data for table Equipment

EquipmentCode	EquipmentDesc
0	MPPT Controller
1	Pi
3	Panels
4	Batteries
5	Modem
6	Environment
7	DVB-T
8	DVB-S

Table structure for table Periods

Column	Type	Null	Default
PeriodCode	int(11)	No
PeriodDesc	char(20)	No
Cumulative	tinyint(1)	No	1

Data for table Periods

PeriodCode	PeriodDesc	Cumulative
0	Instant	0
1	Total	1
2	Day	1
3	Month	1
4	Year	1
5	LastFull	1
6	1 min Avg	0
7	5 min Avg	0
8	15 min Avg	0

Table structure for table Readings

Column	Type	Null	Default	Links to
ReadingPoint	datetime	No
SourceCode	int(11)	No		Sources (SourceCode)
EquipmentCode	int(11)	No		Equipment (EquipmentCode)
PeriodType	int(11)	No		Periods (PeriodCode)
ReadingType	int(11)	No		ReadingTypes (ReadingTypeCode)
Direction	tinyint(4)	No
ReadingValue	double	No

Table structure for table ReadingTypes

Column	Type	Null	Default
ReadingTypeCode	int(11)	No
ReadingTypeDesc	char(20)	No
UnitDesc	char(20)	No
UnitSymbol	char(2)	No

Data for table ReadingTypes

ReadingTypeCode	ReadingTypeDesc	UnitDesc	UnitSymbol
0	Voltage	Volts	V
1	Current	Amps	A
2	Temp	Celcius	C
3	Status
4	Energy	WattHours	Wh
5	Power	Watts	W
6	SignalIcon
7	NetworkType
8	ConnectTime	Seconds	s
9	Data	Bytes	B
10	RSCP
11	ECIO
12	DataRate	Baud	Bd
13	Pressure	Pascals	Pa
14	Humidity	Percent	%
15	Illumination	lux	lx
16	Latitude	Degrees	dg
17	Longitude	Degrees	dg
18	Altitude	Degrees	dg
19	Satellites
20	HDOP
21	Speed	Metres/Sec
22	Course	Degrees	dg
23	Load Avg

Table structure for table Sources

Column	Type	Null	Default
SourceCode	int(11)	No
SourceDesc	char(20)	No

Data for table Sources

SourceCode	SourceDesc
0	MPPT Controller
1	Charge Shunt
2	Load Shunt
3	Calculated
4	Pi
5	Modem
6	Speedtest.net
7	ESP8266
8	TV
9	Weather
10	GeoTracker
